Trace a PayGlocal payment from Pay Now to a Paid invoice. The customer never enters card details on your site — the gateway hands off to PayGlocal's hosted PayCollect checkout, then verifies the signed result before touching the invoice.
The journey at a glance
| Step | What happens | Where |
|---|---|---|
| 1. Pay Now | Customer clicks Pay Now on their invoice | Your WHMCS |
| 2. Encrypt & sign | Gateway builds an encrypted, signed request and gets a redirect URL | Your server ↔ PayGlocal |
| 3. Hosted checkout | Customer pays on PayGlocal's secure page | PayGlocal |
| 4. Verified callback | PayGlocal returns a signed result; the gateway verifies its signature and cross-checks the status | Your server ↔ PayGlocal |
| 5. Marked paid | The signature-verified result marks the invoice Paid; the customer returns | Your WHMCS |
Step 1 — Customer clicks Pay Now
Customer opens the invoice, selects PayGlocal, and clicks Pay Now. Nothing sensitive is collected on your page.
Client Area → Invoices → Pay Now
Step 2 — Request is encrypted and signed
The gateway protects the request before sending it:
| Layer | Purpose | Key used |
|---|---|---|
| JWE (JSON Web Encryption) | Encrypts the payload so only PayGlocal can read it | PayGlocal's public key |
| JWS (JSON Web Signature) | Signs the payload so PayGlocal can prove it came from you | Your merchant private key |
Both rely on the RSA key pair you configured — see PayGlocal key setup. PayGlocal validates the request and returns a one-time redirect URL.
Step 3 — Customer pays on the hosted checkout
The customer is redirected to PayGlocal's PayCollect hosted page and completes the payment there. Card details are entered on PayGlocal's environment — never on your server — keeping your PCI scope small and letting PayGlocal handle 3-D Secure.
PayGlocal → PayCollect hosted checkout
Step 4 — Result is verified and cross-checked
PayGlocal sends a signed (JWS) callback to your WHMCS. The gateway runs two checks:
| Check | Role | On failure / disagreement |
|---|---|---|
| Signature verification (JWS) | Authoritative gate. Verifies the callback with PayGlocal's public key. | If the signature can't be verified, the callback is rejected and the invoice is left untouched. |
| Status-API cross-check | Best effort. Confirms the final status and fills in details the callback doesn't carry (merchant transaction ID, amount). | If the status API disagrees, its status is trusted; if it's unreachable, the gateway proceeds with the signature-verified result and notes this in the Gateway Log. |
Signature is the gate
The signature check is what protects you against spoofed or replayed callbacks — an unsigned or tampered message is never accepted. The status cross-check is a best-effort confirmation, not a second required gate.
Step 5 — Invoice is marked paid
On a signature-verified success, the gateway records the payment and sets the invoice to Paid, then returns the customer to a WHMCS confirmation. Every step is written to the Gateway Log.
When things don't complete
- Abandoned or declined — no signed success callback arrives, so the invoice stays unpaid.
- Paid at PayGlocal but not updated in WHMCS — check Utilities → Logs → Gateway Log; it records the verification and status-check outcomes. See Troubleshooting.
Payments require an active license
Payment processing is gated by your license. If the license is inactive, the gateway will not process payments. See Licensing.
